QuBe Quick Milk (1G)

QuBe Quick Milk (1G)

Performance

Daily output

100 cups

Espresso

Cappuccino

Americano

Drip coffee

Cafe creme

Hot water

Energy consumption
per day

Daily output

100 cups

Espresso

Cappuccino

Americano

Cafe creme

Hot water

Energy consumption
per day

Energy loss/day

Noise level during use

<70 dB

For more information about the delivery capacity and energy consumption of Egro coffee machines, please visit: HKI CERT / Homepage

Technical Specification

Color

black

Notes

The touchscreen frame is available in two colours: black or grey.

Dimensions

Width

368 mm /

14.5 inch

Height

585 mm /

23 inch

Depth

554 mm /

21.8 inch

Weight

27 kg /

59.52 lb

Beverages
  • Espresso
  • Americano
  • Cafe creme
  • Cappuccino
  • Latte macchiato
  • Hot Milk
  • Hot milk foam
  • Hot water
Operating Panel
  • Auto on off

    AUTO ON OFF
    On the technical and/or manager menu, it is possible to set the times for the machine to turn on and off automatically for each day of the week.

  • Touchscreen

    TOUCHSCREEN
    The intuitive touchscreen interface is designed to easily select drinks, navigate through the setting menus and upload video images to customise the machine touchscreen.

Interface

7” Touchscreen

Programmable beverages

27
Coffee
  • 9-16 g brewing chamber
  • Grinder
  • Hot water bypass (1 cup of Americano)

    HOT WATER BYPASS
    The hot water bypass allows a specified amount of hot water to be added directly into the cup, either before or at the end of brewing a coffee-based beverage. The hot water from the bypass does not pass through the ground coffee, thus preventing the effects caused by over-extraction. The hot water bypass can be configured for single cup (One, Next, QuBe, MoDe), ideal for the preparation of one cup of Americano, or for dual cup for the preparation of two cups of long coffee (One, Next).

Grinding burrs

steel 44 mm

Coffee bean hopper capacity

0.6 kg / 1.3 lb
Water
  • Right side hot water outlet

    RIGHT SIDE HOT WATER OUTLET
    Hot water for tea and infusion preparation is dispensed from the water wand located on the right side of the machine. For any given recipe it is possible to program the dosages and water temperature.

Milk
  • Quick Milk

Milk System

Quick Milk

Power

Power supply

100-125 V, 50-60 Hz (1.4 kW)
220-240 V, 50-60 Hz (1.7 kW)

Water supply

Water mains connection or built-in 4.5-litre water tank

Hydraulic circuit

Coffee Boiler

0.6 liter

Thermoblock

Instant steam for heating milk

Cleaning

Automatic cleaning

yes

Cleaning cycle time

14 mins
Fridges
  • Quick Milk fridge (4 liters)
Extra Features
  • Cake crusher

    CAKE CRUSHER
    The cake crusher reduces the volume of the used coffee grounds in the drawer to improve the capacity of the container and reduce the number of times that it has to be emptied.

  • Lock package

    LOCK PACKAGE
    Specifically designed for self-service mode, this kit includes locks for the hoppers, the inlet for the washing tablets, and the grounds drawer.

  • MDB Protocol

    MDB PROTOCOL
    The machine can be connected to all external payment systems that
    are compatible with the MDB communication protocol.

  • Connect telemetry system (wi-fi only) (optional)

    CONNECT
    Connect is a powerful IoT solution developed by Rancilio Group, to gather and easy analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables and graphs, Connect gives you a ready to use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.
